Parameters:

Measurement range: 30Pa~300Pa / 100Pa~500Pa
Degree of protection: IP54
Max. differential pressure: 5000Pa
Electrical rating value: ＜5A/250VAC ＜4A/30VDC
Storage temperature: -40~85℃
Min. actuating pressure: standard: 20Pa; min.starting
　　　　      　　　　　　   interval:10Pa(range: 20~30Pa)
Linearity: range 30~300Pa ＜±2.5Pa
Installation direction: vertical(standard installation style)
Hose connection: pipeΦ6.2mm
Casing material: plastic PCdiaphragm material: silicone LSR
Service life: mechanical period ＞1000000 switching cycles
Weight: 120 grams without bracket
  　　   144 grams with bracket type C
Repeatability: ＜±0.025mbarIn the ranges 0.2 to 3mbar
